Ibanez TS808HWV2 Tubescreamer Handwired Next-Gen
from
267.48€
Ex Tax: 267.48€
397.56€
Ex Tax:397.56€
405.69€
Ex Tax:405.69€
446.34€
Ex Tax:446.34€
At Ibanez, we sought to take the iconic Tube Screamer and push it further by re-envisioning the flagship, hand-wired model. We evaluated every component while aiming to stay true to the pedal’s transparent and mid-range-focused tone. After numerous prototypes, we concluded the JRC NJM4558 op-amp was essential to achieve the Tube Screamer’s legendary sound. At the same time, this new design can have a wider range of sounds thanks to the addition of high-end components such as MOGAMI OFC cables, which further enhance the benefits of a hand-wired pedal. Additionally, a boost has been added to the final stage of the circuit, increasing the maximum output level by +6dB. Its look has also been revamped, giving it a high-end appearance while retaining the traditional shape.
Specifications
| Controls | OVERDRIVE, TONE and LEVEL |
| DC Jack | Standard 2.1mm DC Jack (Center Negative) |
| I/O Jacks | INPUT, OUTPUT |
| Required Current | 7mA@9V / 11mA@18V |
| Power Supply | One 9-volt battery (006P) or external AC adapter (Use only DC 9-18V (Center-negative)) |
| Made in | Japan |
| Exterior length (mm) | 133 |
| Exterior width (mm) | 77 |
| Exterior height thickness (mm) | 60 |
| Batteries required | 9V x 1 |
