JEM77P
PIA/JEM/UV
Premium Neck
Smooth, fast & comfortable, the JEM Maple/Walnut Premium neck.
Tree of Life Inlay
Matched color Tree-Of -Life inlay.
Monkey Grip
One of JEM's most recognizable features: Steve Vai's signature monkey grip. Crank your amp up, grab that baby and hold on for dear life.
Edge-Zero II tremolo bridge
The Edge Zero II bridge design features a lower profile tremolo for playing comfort and stud lock function for stable tuning.
Neck Dimensions
Scale : 648mm//25.5"
Width at NUT (a): 43mm
Width at 24F (b): 58mm
Thickness at 1F (c): 18mm
Thickness at 12F (d): 20mm
Radius : 400mmR
Switching System
When the pickup selector switch is in neck position, the neck humbucker is selected.
When the switch is between neck and center position, the bridge side of the neck humbucker and the center pickup are selected.
When the switch is in center position, the center pickup is selected.
When the switch is between the center and bridge position, center pickup and the neck side of the bridge humbucker are selected.
When the switch is in bridge position, the bridge humbucker is selected.
Controls
With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body.
Closest to the neck is the five-way pickup selector switch.
Closer to the input jack is the tone knob.
The volume knob is located right above the five-way pickup selector switch.
