XPTB720
X IronLabel
Wizard II-7 5pc Maple/Walnut neck
Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability for demanding players.
Ebony fretboard
Ebony produces tight lows and mid range with a strong attack in the high end and features a quick response and rich sustain.
Okoume body
The Okoume body provides a bright and solid sound.
DiMarzio® D-Activator pickups
DiMarzio® D-Activator pickups have a powerful, clean, and open sound with excellent harmonic overtones and very tight low-end response.
Gotoh® machine heads
Gotoh® machine heads provide super precision, smooth feel, and minimal back lush.
Edge-Zero II tremolo
The Edge Zero II bridge design features a lower profile tremolo for playing comfort and stud lock function for stable tuning.
Luminescent side dots
The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.
Neck Dimensions
Scale : 648mm//25.5"
Width at NUT (a): 48mm
Width at 24F (b): 68mm
Thickness at 1F (c): 19mm
Thickness at 12F (d): 21mm
Radius : 400mmR
Switching System
When the pickup selector switch is in the neck position, the neck pickup is active.
When the switch is in the center position, both the neck and bridge pickups are selected.
When the switch is in the bridge position, the bridge pickup is selected.
Controls
With the guitar held in the playing position, there are a switch and two knobs along the lower edge of the body.
From the end of the body towards the neck they are; the three-way pickup selector switch, tone knob, and volume knob.
